METZNER TRIATHLON

More efficiency and cost savings in control cabinet construction, even for small series

Triathlon L 0525/1060:

bis zu 450 Drähte pro Stunde

Triathlon S 0525/1060:

bis zu 300 Drähte pro Stunde

Fully automated. Efficient. Ready to install.

Metzner Triathlon machines set new standards in control cabinet construction: They deliver all wires fully assembled, ready for installation, and in the correct wiring sequence. Fully automatic and without the need for personnel! The machines use as input a file containing a list of all wires required for a control cabinet. Metzner Triathlon machines operate approximately 15 times faster than a qualified technician. The Triathlon S delivers 300 wires per hour, and the Triathlon L delivers 450 wires with an average length of 1500 mm and ferrules on both ends.
Metzner_Triathlon_ROI
This means that the Metzner TRIATHLON machines pay for themselves in approximately 2 years with an annual production volume of 200 control cabinets, each containing around 500 wires.
Metzner_Triathlon_efficience
TRIATHLON L 0525/1060
TRIATHLON L 0525/1060
  • Automatic wire change: 36-fold
  • Wire output: chain bundles and/or wire rails
  • Max. number of wire rails: 15 pcs.
  • Cycle time: 7 sec.
TRIATHLON S 0525/1060
TRIATHLON S 0525/1060
  • Automatic wire change: 12-fold
  • Wire output: chain bundles or wire rails
  • Max. number of wire rails: 5 pcs.
  • Cycle time: 11 sec.
