THE COMFORTABLE WAY TO HANDLE INDEXABLE INSERTS

Press automation for medium to large lot sizes: Metzner RPA 10-SL

The Metzner RPA 10-S has an integrated magazine system for up to ten sintering plates with automatic sintering plate change. So, it automatically removes empty sintering plates from the magazine, loads them and then returns them. Thanks to the sintering plate change automation, the powder press automation works independently over a longer period of time, without loading and unloading processes leading to a press stop. Weighing or deburring of the pressed parts is also fully automatic.

With the integrated 4-axis SCARA robot, the machine achieves very high system speeds of up to 30 strokes/min. This makes it ideally suited for connection to electric presses with high cycle rates.

This sintering plate change automation is conveniently operated via the integrated control system or the mobile operating terminal.

Works
independently
Easy
to operate
Very high speed
up to 30 strokes per minute
Up to 10 sinterplates
of any type
at a time
Interfaces to
presses from different suppliers

TECHNICAL DATA

Performance data	RPA 10-SL
Storage capacity: Empty sinter trays	10
Storage capacity: Loaded sinter trays	10
Sinter tray changing time	approx. 5 sec.
Sinter tray size	max. 400 mm x 300 mm x 65 mm \| 1’4″ x 11.8″ x 2.6″
Sinter tray design	common designs
Performance references: pick & place	30 parts/min.
Performance references: pick & place with deburring	18 parts/min.
Speed	up to 2 m/sec. \| 6’7″/sec.
Repeatability	+/- 0.05 mm \| 0.002″
Mounting	Mounting bracket

Machine parameters
Power supply	3~400 V, 50/60 Hz, 32 A or transformator
Drive	electronic
Compressed air supply	6 bar \| 87 PSI
Dimensions	2,100 mm x 1,050 mm x 2,500 mm \| 6’11” x 3’5″ x 8’2″
Weight	1,300 kg \| 2,866 lbs

Optional equipment
Gripper changing system
Gripper system	option
Cleaning system	option
Display	Touch 19″ colour
Weighing system	option
Pneumatic deburring	option
Mechanical deburring	option
